ORiK Laser Scanning

Know what is really there before you draw, price or build.

ORiK Laser Scanning measures existing buildings with 3D laser scanners and turns the scan into the files you work in: a point cloud, 2D CAD plans or a Revit model. We work across Rhode Island, Massachusetts and New Hampshire.

  • Point cloud, CAD or Revit
  • For architects, contractors and owners
  • Based in Smithfield, RI
Space
Retail unit
Floor area
2,400 sq ft
Scan positions
5 shown
Old drawings said
60'-0" × 40'-0"
The scan shows
59'-10 1/2" × 40'-1 3/4"
Deliverable
2D CAD floor plan

Sample space for illustration. Not a real project.

700K+
square feet digitized
178+
clients served
20+
years in AEC

What do you need?

Pick the one that fits. We will show you what you get.

Plans drawn from measurements, not guesses.

We scan the building and draw dimensioned 2D CAD plans from the scan. Sections, elevations and reflected ceiling plans are available when you need them.

Quote my floor plans

Start design on a model you can trust.

We deliver a Revit model of the existing building, up to LOD 300. You agree the level of detail with us before we start, so you only pay for what you will use.

Quote my Revit model

We scan. Your team models.

You get a registered point cloud in .RCP, .E57 or .LAS, with a short report on coverage and accuracy. It opens in Revit, AutoCAD and most design software.

Quote my scan

Catch a problem while it is still cheap.

We scan the work in place and compare it with the design. You get a list of what matches and what does not, with the measurements.

Quote a progress check

Know the real size and condition first.

A quick scan gives you true floor areas, ceiling heights and a 3D record of the building before you sign a purchase or a lease.

Quote a pre-purchase scan

Old drawings are a starting point. They are rarely the truth.

Buildings change every time someone renovates, and the drawings almost never keep up. Designing or pricing from them works until the first wall is opened. A laser scan records the building as it stands today, to within a few millimeters.

The kind of difference a scan finds
Measured itemOld drawingScanOff by
Overall width60'-0"59'-10 1/2"1 1/2"
Ceiling height12'-0"11'-4"8"
Column spacing20'-0"19'-9 1/4"2 3/4"
Storage room wallNot shownLocatedMissing

Example values for illustration, from the sample unit above.

Tape measures miss things

Hand measuring is slow, skips what is hard to reach, and cannot be checked later. A scan can be measured again from your desk.

Bad dimensions become change orders

A wall that is two inches off is a small note in design and an expensive fix in the field.

Site visits eat the schedule

One scan visit replaces the repeat trips to check a dimension someone forgot.

What you actually get from us.

Four of the deliverables we produce. These are samples we drew for this page. The numbers are made up.

As-built floor plan

Sample

Retail unit, 2,400 sq ft. Drawn in AutoCAD from the registered point cloud.

SALES FLOORSTORAGERRCLG 11'-4"CLG 9'-0"59'-10 1/2"40'-1 3/4"19'-11 1/4"22'-5 1/2"3'-0" DOOR
Sheet A-101, existing floor plan. Dimensions are taken from the scan.
File format
.DWG, plus a PDF set
Shown
Walls, doors, glazing, columns, room names, ceiling heights
Also available
Reflected ceiling plan, sections, interior and exterior elevations
Layers
Set up to your CAD standard if you send it

The old lease plan called this unit 60 by 40 feet. It is 1 1/2 inches shorter and 1 3/4 inches deeper, and the storage wall is not where the plan showed it.

Revit model of existing conditions

Sample

The same unit, modeled from the scan and cut open at 4 ft 6 in. so you can see inside.

3D view with a section box. Blue surfaces show where the model is cut.
File format
.RVT, in the Revit version you use
Level of detail
Up to LOD 300, agreed in the quote
Modeled
Walls, doors, glazing, columns, floors, ceilings, stairs
By request
Structural framing, visible mechanical, electrical and plumbing
Not modeled
Furniture and loose equipment, unless you ask

LOD 300 means each element has its real size, shape and position, so you can design and coordinate against it.

Registered point cloud and scan report

Sample

For teams that model in-house. You get the measured points and a short report on how they were captured.

A small building drawn as a cloud of measured points.
Illustration. Each dot stands for a measured point. A real scan holds millions.
File formats
.RCP, .E57 or .LAS
Scanner
Leica RTC360
Scan positions
14
Registration error
2 mm average between scans
Coverage
All rooms. Above the ceiling at three access panels.
Not captured
Mechanical room. It was locked on scan day.

The report tells you what was scanned, how well the scans line up, and what we could not reach.

Construction progress check

Sample

Level 2, after steel and slab. The scan is compared with the design model.

Item checkedDesignAs builtDifferenceResult
Slab edge at grid line A0"+3/8"3/8"Within tolerance
Steel column C4, plumb0"1 1/8" east1 1/8"Needs a decision
Floor to floor, level 1 to 212'-0"11'-11 5/8"3/8"Within tolerance
Duct shaft opening4'-0" × 6'-0"3'-10 1/2" × 6'-0"1 1/2"Needs a decision
Embed plates, north wall1414NoneAll found

Two items need a decision before the curtain wall and the ductwork are ordered. Finding them now costs a phone call. Finding them at installation costs a change order.

Tolerances are set by your project team. We report the measurements; your architect and contractor decide what to do.

Four steps from first call to final files.

StepWhat we doWhat you get

1Scope

We ask about the building, what you need drawn or modeled, and your deadline.

What you getA written quote with the scope and a delivery date.

2Scan

We scan on site with the scanner that suits the building. Occupied spaces can stay open.

What you getThe whole building measured in one visit, in most cases.

3Process and draw

We join the scans into one point cloud, check it, and draw or model from it.

What you getFiles in the format and to the standard you asked for.

4Deliver and review

We send the files and walk you through them.

What you getA scan report, and help if a file will not open.

See all services and file formats

Who we work with

Architects and designers

Start design from accurate plans or a Revit model, without sending your own staff to measure.

Scanning for architects

Contractors and subcontractors

Check existing conditions before you price, and check the work in place before the next trade covers it.

Scanning for contractors

Owners, developers and brokers

Get true floor areas and a permanent record of your building for leasing, buying or renovating.

Scanning for owners and brokers

I have worked as a construction laborer, an architectural designer, a project engineer, a VDC engineer, a project manager and an owner's representative. Every one of those jobs was harder when the drawings were wrong. We provide the technical truth for your building.

Kirlos SyfyenFounder, ORiK Laser Scanning

We come to your building.

We are based in Smithfield, Rhode Island, and travel to sites across three states.

Rhode Island

Providence, Warwick, Cranston, Pawtucket, Newport and the rest of the state. Most sites are under an hour from us.

Massachusetts

Greater Boston, Worcester County, the South Coast and the Merrimack Valley.

New Hampshire

Nashua, Manchester, Concord, the Seacoast and nearby towns.

Questions people ask first

What is 3D laser scanning?

A laser scanner measures millions of points on every surface it can see. Together the points form a 3D record of the building called a point cloud. Plans and models are then drawn from it.

How accurate is it?

It depends on the scanner and the distance. Our tripod scanners are rated by Leica at about 2 to 4 mm at 10 m. The handheld scanner is rated at about 10 mm indoors and is used where speed matters more.

Do we have to close the building?

No. We can scan occupied spaces and active job sites. People moving through are filtered out of the data.

How much does it cost?

It depends on the size of the building, how complex it is and what you need delivered. Send us the details and we will give you a written quote before any work starts.

Where do you work?

Across Rhode Island, Massachusetts and New Hampshire.
